Product Details

Premium UniFi doorbell with an enhanced package detection camera and integrated display.

Streams 1080p HD video at 30 FPS
Dual-band WiFi and GbE connectivity
(1) 5MP camera with an IR LED [Video output: 1600x1200 (2MP), 30 FPS]
(1) 8MP package camera [Video output: 1600x1200 (2MP), 2 FPS, no IR LED]
Two-way audio with echo cancellation

Technical Specifications:

	OVERVIEW
Dimensions	160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6")
IR Night Vision	6 m (20 ft)
Smart Detections (People, Vehicles, Animals)	Yes
Resolution	Compact desktop, wall, magnetic
Field Of View	Main camera: H: 138°, V: 114°, D: 155° Package camera: H: 97.5°, V: 79.4°, D: 118.2°
Audio	Two-way audio
Weatherproofing	IPX4
Mounting	Flat wall, 20° wedge (Included)
	PERFORMANCE
Networking Interface	802.11a/b/g/n/ac WiFi; Bluetooth 5.0 GbE support (With UACC-Adapter-DBPOE)
Video	Max. Frame Rate: 30 FPS Resolution: Main camera: 2MP 1600 x 1200 (4:3) Package camera: 2MP 1600 x 1200 (4:3)
Optics	Sensor: Main camera: 5MP CMOS Package camera: 8MP CMOS Lens: Fixed focal length Night Mode: Built-in IR LED illumination and IR cut filter
	HARDWARE
Max. Power Consumption	30W
Supported Voltage Range	37—57V DC
Power Method	16—24V AC, 1.25A Max., 50/60 Hz USB-C power cable, 5V DC, 2A
Processor	Quad-core Arm® Cortex®-A53 based chip
Weight	Device: 253 g (8.9 oz) With flat wall mount: 286 g (10.1 oz) With 20° wedge mount: 325 g (11.5 oz)
Enclosure Material	Polycarbonate, aluminum alloy
Mount Material	Flat wall mount: aluminum alloy 20° wedge mount: polycarbonate
Button	(1) Ring button (1) Factory-reset
Compatible Chimes	Mechanical: Broan-NuTone: LA126WH, LA11WH, LA39WH Heath Zenith: SL-2735 Craftmade: CTPW-RG Newhouse Hardware: CHM3D Digital IQ AMERICA: DW-2850, DW-2840 Broan-NuTone: LA600WH
Ambient Operating Temperature	10 to 40° C (14 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	FCC, IC, CE
NDAA Compliant	Yes
