Product Details

A compact, Layer 2, 8-port GbE PoE switch with versatile mounting options.

52W PoE availability with the included AC power adapter
42W PoE availability with PoE++ input
17W PoE availability with PoE+ input
8W PoE availability with PoE input

Technical Specifications:

	OVERVIEW
Dimensions	203 x 76 x 33 mm (8 x 3 x 1.3")
Port Layout	1 GbE RJ45: 8 (7 PoE+; 1 PoE++ input) (1G/100M/10M)
Max. PoE Output	PoE++ input: 42W PoE+ input: 16W 60W PoE adapter input: 42W 60W AC adapter input: 52W 210W AC adapter input: 202
Form Factor	Compact desktop, wall, magnetic
	PERFORMANCE
Switching Capacity	16 Gbps
Total Non-Blocking Throughput	8 Gbps
Forwarding Rate	12 Mpps
Supported VLANs	256
MAC Address Table Size	4000
Layer 2 Features	STP & RSTP Egress Rate Limit Flow Control Storm Control Multicast & Broadcast Rate Limiting Port Isolation Port Mirroring Jumbo Frames Loop Protection
	HARDWARE
PoE Ports	7 PoE+ 1 PoE++
Max. PoE Wattage per Port by PSE	PoE+: 30W
Max. Power Consumption	9W (Excluding PoE Output) with PoE input 8W (Excluding PoE Output) with adapter input 210W (Including PoE Output) with 210W AC adapter input
Power Method	(1) AC/DC adapter (Included) (1) PoE++
Power Input Method	DC input PoE
Power Supply	AC/DC, external, 60W
Supported Voltage Range	50—57V DC/PoE
Management	Ethernet
Heat Dissipation (Excluding PoE Output)	30.708 BTU/hr 27.296 BTU/hr
Weight	Device: 320 g (11.3 oz) Wall mount: 45 g (1.6 oz) Adapter: 330 g (11.6 oz)
Enclosure Material	Polycarbonate
Ambient Operating Temperature	PoE++ input: -30 to 60° C (-22 to 140° F) 60W AC adapter input: -20 to 60° C (-4 to 140° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	FCC, IC, CE
NDAA Compliant	Yes
	SOFTWARE
UniFi Network	Version 8.0.7 and later
