Panamax MIW-XT Max-In-Wall Power & Signal Bay, 15A Code Compliant Extension System
Art: MIW-XT
Call for Availability
Increments of 1
Minimum of 1
Maximum of
Sale price
$229.45
-100%
Regular price
$0.00
Regular price
$229.45
Unit price
per
Couldn't load pickup availability
Description
Product Details
MIW-XT extends noise free, safe power from Panamax / Furman Power Management components to remote panel displays, ceiling mounted video projectors and powered sub-woofers. Discreetly hides behind electronic equipment for a neat, clean, code compliant and professional installation.
Features
- Ultra-thin profile can allow equipment to hang less than one inch from the wall.
- EMI/RFI noise filtration built into outlet receptacle.
- Power and signal lines are hidden in the wall behind panel displays for a clean, tidy and professional installation.
- Extend Connected Equipment Policy to remote equipment when used with Panamax/Furman Power Management components.
- Accommodates optional MIW Signal Line Modules (sold separately, contact Panamax or Furman).
- CSA Certified for code compliant installations.
- 3 Year Product Warranty
Specifications
- General
Family: In Wall
Line Voltage: 120 (Volts)
Number of Outlets: 1
Outlet Descriptions: 1 filtered outlet
Compliance: CSA
USB Charging: N/A
Low Voltage Trigger: N/A
AC Power Cord: 6 ft. detachable inlet power cord. 11 inch flat plug output cord.
Dimensions: 4.75" W x 0.25" D x 4.75" H
- AC Protection
AC Protection Technology: N/A
Undervoltage Shutoff: N/A
Over-Voltage Shutoff: N/A
Maximum Current Rating: 15 (Amps)
Initial Clamping Level: N/A
- Filtration
Filtration Technology: RFI/EMI Filtration
Signal Line Protection: No
- Shipping Info
Length: 7.7 (Inches)
Width: 5.2 (Inches)
Height: 6.9 (Inches)
Weight: 2.9 (Lbs)
Unit of Measure: Each
UPC: 050616008488
Master Pack Qty: 6
