Simplified eARCEX eARC Only Extender with CFC
Art: eARCEX
In stock: 5 available
Increments of 1
Minimum of 1
Maximum of
Sale price
$449.99
-100%
Regular price
$0.00
Regular price
$449.99
Unit price
per
Couldn't load pickup availability
Description
Simplified eARCEX eARC Only Extender with CFC
Product Details
eARCEX
eARC Audio Extender with CEC
The eARCEX is an audio-only extender designed to take the eARC audio of a display to an amplifier or other eARC/ARC enabled device and transmit it in full bandwidth up to 100m (330ft) over category cable. CEC transmission is supported, so the display’s remote can be used to control the volume of the amplifier/AVR. The eARCEX also supports optical S/PDIF transmission up to 100m. The eARCEX is designed to be a simple plug-and-play device to get eARC/ARC from the display back to the eARC/ARC-enabled amplifier or other eARC/ARC device that is too far away to use a traditional HDMI cable.
Features:
|
• eARC Audio or Optical S/PDIF is extended over a single category cable |
|
• eARC Audio formats include: PCM 2.0/5.1/7.1ch, DD, DD+, DTS, Dolby TrueHD, DTS-HD MA, Dolby Atmos |
|
• HDCP 2.2, HDCP 1.4, and DVI compliant |
|
• ARC Audio formats include: PCM 2.0 or Dolby/DTS 5.1 |
|
• Optical Audio formats include: PCM 2.0 or Dolby/DTS 5.1 |
|
• Supports CEC for amplifier volume control, etc. |
|
• DIP switch enables optical S/PDIF if eARC/ARC is not available (CEC is lost in this mode) |
|
• Powered from one end (either) |
|
• Compact size |
|
• 3-Year warranty |
Specifications:
|
Technical |
|
|
Supported Audio Formats |
eARC: PCM 2.0/5.1/7.1ch, DD, DD+, DTS, Dolby TrueHD, DTS-HD MA, Dolby Atmos ARC: PCM 2.0CH, Dolby 5.1CH, DTS 5.1CH S/PDIF: PCM 2.0CH, Dolby 5.1CH, DTS 5.1CH |
|
Transmission Distance |
100m/328ft |
|
ESD Protection: Human Body Model |
±8kV (Air-gap discharge) ±4kV (Contact discharge) |
|
Connections |
|
|
Transmitter |
Inputs: 1 x HDMI (eARC in) Type A [19-pin female] 1 x optical S/PDIF 1 x Micro USB, power connection port Outputs: 1x CAT out [RJ45, 8-pin female] |
|
Receiver |
Inputs: 1x CAT in [RJ45, 8-pin female] 1x Micro USB, power connection port Outputs: 1x HDMI (ARC out) Type A [19-pin female] 1 x optical S/PDIF |
|
Mechanical |
|
|
Housing |
Metal Enclosure |
|
Color |
Matte Black |
|
Dimensions |
Transmitter/Receiver 90mm/3.5” [W] x 72mm/2.823” [D] x 20mm/.79” [H] |
|
Weight |
184g/6.5oz. |
|
Power Supply |
Input: AC 85 - 230V 50/60Hz Output: DC 12V/1A (US/EU standard, CE/FCC/UL certified) |
|
Power Consumption |
5.6W Max |
|
Operating Temperature |
32 - 104°F / 0 - 40°C |
|
Storage Temperature |
-4 - 140°F / -20 - 60°C |
|
Relative Humidity |
20~90% (non-condensing) |
