Simplified MVPS 9x1 Instant-Switching HDMI Switch with Multiview

Product Details

The MVPS HDMI Switch features nine HDMI inputs and one HDMI output with a 3.5mm mini-jack audio breakout. Output resolution can be set to many different resolutions up to 4K @ 30Hz.

Applications include presentation switches where multiple sources need to be shown on a single display and control room/command center type of uses. The instant switching makes this a perfect device for live performances such as public speaking and houses of worship applications. There is no "wait time" when switching from source to source. The output can also be configured to show 2 sources (side by side and PIP), 4 sources (quad and 3 collaboration modes), and 9 sources.

Features

• HDMI1.4 / HDCP1.4 Compliant

• Supports multiplexed HDMI 9-input and 1-output

• Selectable output resolutions;(1024x768/1360x768/720p/1080i/1080p/4K)

• Single, Side by side, PIP, Quad, 3 versions of Collaboration format, and a 9-view options

• Seamless switching

• Up and Down Scaling

• Multiple Output Resolutions up to 4K @ 30Hz

• Web GUI Interface

• Supports 2-channel audio and has an audio breakout

• Web GUI for setup and control

• Manual, IR, RS232, and IP Control Options

• 3 Year Warranty

Downloads

Manual

Spec Sheet
