Simplified SP12S 1 to 2 HDMI Splitter

Name: Simplified SP12S 1 to 2 HDMI Splitter
Brand: Simplified
SKU: SP12S
Price: 99.99 USD
Availability: InStock

Art: SP12S

In stock: 3 available

Quantity: (In cart: 0)

Increments of 1 Minimum of 1 Maximum of

$99.99 -100% $0.00

$99.99

Product Details

The SP12S in an HDMI2.0b splitter with scaling, EDID management, and audio breakout. It supports resolutions up to 4K2K@60Hz (4:4:4) and HDCP 2.2/1.4. The EDID can be copied (output 1) or mixed. Each output can be set to 1080p or to the EDID setting. Also, audio can be extracted via the optical SPDIF and/or the 3.5mm mini jack.

Features & Benefits

Compliant with HDMI2.0b, HDCP2.2 and DVI 1.0
Supports video formats up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2, and up to 4k2k@60Hz with 12bit YCBCR 4:4:4
Selectable EDID setting (Copy output 1 or Mix)
Selectable Scaling will allow each output to either follow the EDID setting or scale to 1080p
Optical S/PDIF and 3.5mm Mini jack audio breakout
Supports HDR 10+ and DolbyVision™
Supports high resolution VESA mode video format up to QSXGA@60Hz
Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
3-Year Warranty

Specifications


Video Bandwidth	600MHz./18Gbps
Input Ports	1 HDMI Type A [19 Pin female]
Output Ports	2 HDMI Type A [19 Pin female] 1 L/R 3.5mm mini jack, 1 Optical S/PDIF
Output Resolution	480i~1080p 50/60Hz., 4Kx2K 24/25/30/50/60Hz
ESD Protection: Human Body Model	±8 kV (air-gap discharge)
	±4 kV (contact discharge)
Power Supply	5V/1A DC (US/EU standards, CE/FCC/UL Certified)
Dimensions	120mm/4.73" [W] x 56mm/2.2" [D] x 16mm/0.63" [H]
Weight	200g/7oz.
Chassis Material	Metal
Operating Temperature	0 °C~40 °C/ 32 °F~104 °F
Storage Temperature	−20 °C ~ 60 °C/−4 °F ~140 °F
Relative Humidity	20~90% RH (non-condensing)
Power Consumption (Max)	5W
